Line LOK 7.90 E / 10.90 E / 13.90 E

LOK E, rail – road vehicle equipped with an electrical motor.

Description

Zephir is pleased to present on the market LOK E, rail – road vehicle equipped with an electrical motor.
Progression of LOK range, the LOK E has two 30 kW electrical motors (instead of a diesel engine, one for each axle, 1000 Ah, 80 V battery powered.

This vehicle could be on and off – tracked from railways and it can cross tracks to perform cross terminal movements quickly and efficiently at a smaller cost than the LOK range. LOK E range enhances the environmental role in Zephir strategies, that is more and more engaged in designing non – polluting vehicle.

Data Sheet

Lok 7.90 E Lok 10.90 E Lok 13.90 E
Drive Battery powered Battery powered Battery powered
Operator type (road mode) Operator seated Operator seated Operator seated
Dimensions (LxWxH) mm 4800x2500x3400 4800x2500x3400 4800x2500x3400
Service weight t 16 20 24
Max. drawbar pull kN 70 100 120
Max. towing capacity  t 1400 2000 2600
Max. rail speed unloaded/loaded km/h 7 7/17 7/17
Mechanical transmission – (fwd/rev) speeds 1/1 2/2 2/2
Drive motors rating (power system, quantity) kW 30 (AC) 30 x (2) – (AC) 30 x (2) – (AC)
Acid lead battery with centralized refilling system , voltage/nominal capacity V/Ah 80/960 + 80/960 80/960 + 80/960 80/960 + 80/960
On board battery charger V/Ah 80/150 x (2) 80/150 x (2) 80/150 x (2)

Accessories

  • Radio remote control, interlock, ground operator safety remote control
  • Availability of different rail gauge measures
  • Air conditioning inside the cabin
  • Wide range of hooks, couplers and tow bars
  • Pneumatic braking system
  • Railtrack “short-circuit” signalling system and distance proximity sensors
  • In-railing and on-hook video cameras system
  • Cold environment protection “Arctic pack”
  • High temperature pack
  • Multi-Unit configuration
  • Latest engines generation
  • Engine star & stop
  • Driver seat on right side
  • Painting and custom stickers
  • Extended Warranty
  • Availability of other options upon request
